Instruction The DS150 Air grinder is mainly used for the sharpening and polishing work. It’s widely used for cast workshop, metal shop, construction and other projects and works. DS150 Air grinder can use to clear the casting, polishing angle and polishing and so on. It also can match with taper grinder.
Specification

Model	Weight	Length	Air drilling speed	Air consumption	Power	Air hose Dia	Max grind wheel dia
DS150 Air Grinder	6kg	476mm	5500-6600r/min	32.87L/S.kw	1.14kw	16mm	150mm

Spare pare list

Code	Part No	Name	Code	Part No	Name
1	BM12×1.25GB46-76	Nut	19	DS150-13	Valve Sleeve
2	DS150-01	Close Ban	20	15×2.4GB1235-76	O-Ring
3	DS150-02	Pad	21	DS150-14	Nut
4	DS150-26	Grinder Cover	22	DS150-15	Air connection tube
5	DS150-03	Battle	23	DS150-16	Back head
6	DS150-04	Felt packing	24	DS150-17	Governor
7	DS150-05	Felt packing nut	25	DS150-18	Setting ring
8	DS150-25	Precursor	26	DS150-19	Cylinder rear cover
9	DS150-06	Principal axis	27	DS150-20	Muffler
10	202GB276-64	Bearing	28	DS150-21	Lamina
11	DS150-07	Coupler sleeve	29	DS150-22	Rotor
12	DS150-08	Spacer ring	30	DS150-23	Cylinder
13	DS150-10-1	Lead screw	31	DS150-24	Cylinder Cover
14	DS150-09	Setting pin	32	203GB276-64	Bearing
15	B6GB97-76	Gasket	33	M8×20GB21-76	Side bolt
16	M6GB52-76	Nut	34	M8GB52-76	Pad
17	DS150-11	Air inlet valve	36	150×32×32G 462Y:S5P	Grinder wheel
18	DS150-12	Retaining bead flange

DS150 Air grinder
