Crowd control barrier

aluminum alloy series Crowd control barrier is manufactured with the aluminum extruded profile (6063-T5) . The manufacture processes include pipe bending, processing, welding, and assembling.
The product has passed 75kg of side pull test. It is safe to use, light in weight and easy to operate, suitable for protection and separation use in construction scaffolds.

Name of the items		Assembled width	The distance between the two feet	Reference height	Bottom tube height		arc bending diameter		Weight (kg/set)	40 feet cabinet
No.	Specification and Model	A	B	C	D1	D2	G1	G2
1	HL-U-1829	1829	1649	1300	200	60	95	105	8.701	640
2	HL-U-1524	1524	1344	1300	200	60	95	105	7.092	700
3	HL-U-1159	1159	1039	1300	200	60	95	105	5.482	820
4	HL-U-914	914	734	1300	200	60	95	105	3.873	1080
