Compound Crusher is a Business Services product. Key specs — Origin: Henan, China; Price Term: FOB.
Product Description
Vertical Compound Crusher is developed by combining the pre-breakage technology of domestic and foreign countries, and optimizing the key structure parameters.
1. Main Features:
high efficiency,
low energy consumption,
low wear;
excellent quality with competitive price.
2. Technical Parameter:
1. Main Features:
high efficiency,
low energy consumption,
low wear;
excellent quality with competitive price.
2. Technical Parameter:
Model | 800 | 1000 | 1250 | 1500 |
Rotator Diameter (mm) | 650 | 800 | 1000 | 1250 |
Drum Diameter (mm) | 800 | 850 | 850 | 1000 |
Rotator Speed (r/min) | 930 | 769 | 530 | 495 |
Charging Granularity (mm) | 50 | 70 | 100 | 100 |
Discharging Granularity (mm) | 0.5-5 | 0.5-5 | 0.5-5 | 0.5-5 |
Output (T/h) | 10-20 | 25-40 | 45-70 | 50-90 |
Motor Power( kw) | 15-22 | 30-55 | 75-90 | 90-132 |
Weight (kg) | 2500 | 3800 | 5500 | 8000 |
