Coating Lamination Plant
Specifications
- Origin
- India
- Price Term
- FOB
Coating Lamination Plant is a Other Plastic & Rubber Machinery product. Key specs — Origin: India; Price Term: FOB.
Product Description
Offering Coating Lamination Plant:
SR NO. Plant Model Screw Size MM Screw L/D Feed Section Type Die Width (MM) Max working width (MM) Coating thickness range in micron Max Line speed MT/MIN. Max Prod. Capacity (KGS PER HOUR) Total Connected Load (KW) Main Drive (HP) Polymer To be processed Dimension of plant in feet L W H 1 OESL750 65 28:1 SMOOTH FEED 900 750 20 TO 75 100 60 52.5 20 LDPE/PP 40 20 15
2 OESL1500 75 28:1 SMOOTH FEED 1700 1525 20 TO 75 100 110 71.5 25 LDPE/PP 40 20 15
3 OESL1830 75 28:1 SMOOTH FEED 2000 1830 20 TO 75 100 110 75.5 30 LDPE/PP 40 25 15
4 OESL2450 90 28:1 SMOOTH FEED 2600 2450 20 TO 75 60 150 86.5 40 LDPE/PP 40 25 15
5 OESL3000 90 28:1 SMOOTH FEED 3250 3050 20 TO 75 60 175 100 50 LDPE/PP 40 30 15
6 OESL3660 75x75 28:1 SMOOTH FEED 3860 3660 20 TO 75 40 250 120 30x30 LDPE/PP 40 40 15
7 OESL3965 90x90 28:1 SMOOTH FEED 5180 4880 20 TO 75 40 300 145 40x40 LDPE/PP 40 40 15
