China (Mainland) Ship Navigation Radars

Specifications: The series of ns ship navigation radars are first worked out in home, which have reached to the international standard. It adopts the advanced technology both at home and abroad, using a large screen daylight viewing. The series of products is steady and reliable.

Ns sieries navigation radars are fit to all kinds of guest-ship, freighter, fishing boats, mosquito craft, ferryboat etc, in accordance with the requirment of user, we can equip the especial function. TECHNICAL SPECIFICATIONS 1. RADIATIOR Slotted waveguide array 2. RADIATOR LENGTH 120cm 3. HORIZONTAL BEAMWIDTH Less than 2 degree 4.

VERTICAL BEAMWIDTH 24 degree 5. SIDELOBE ATTENUATION Within +/- 20 degree of mainlobe: Less than-20 dB. Outside +/- 20 degree of mainlobe: Less than-23 dB. 6. Polarization Horizontal 7. ANTENNA ROTATION SPEED 22 RPM nominal Model: Sn2001(new) 1. Completely Chinese and the 14-inch daylight raster scanning display(green screen), the operations are simply. 2.

Headline can freely adjust in range of 360 degree on the front-panel. 3. Milimetre and mile can transform each other in order to let users freely select it in various zone. 4. Tracing targets track can make driver adopt some measures in order to aviod collision. 5.

You can set up mobile zaimuth, mobile distance symbols, alarm area, targets zoom, off- center by mouse global. 6. Setting up distance from 0.25 to 72nm. 7. Automatically selecting three pulse wideth and two pulse repeating frequecy, which provides a short distance performance and the best far distance performance. 8. Operation voltage:12.5-40v(dc);power
