Cap Hydraulic Molding Machine

This machine, characterized by easy operation and economy in electricity, water, raw material and labor power, increases its output by three times compared with other plastic injection molding machines with the same power consumption. Automatic temperature control devices and a speed matching system of the extruder and the molding machine are installed to optimize the temperature of molds and materials, which makes the machine durable and stable.

Plastic cap machines are mainly used to produce plastic is our latest high-automatic machine for anti-theft plastic bottle lids such as adding lids,sorting,feeding lids,cutting lids, dropping lids and so maximum output of machine is 18000pcs/hr.

main technical features
min cap diameter 20mm
max cap diameter 45mm
min cap height 10mm
max cap height 25mm
production capacity(30x20size):upto 18000caps/hour
installed electrical power:1KW(50HZ) 20KW(50HZ)
absorbed electrical power:approxmate 15KW(50HZ)
compressed air consumption(approxmate) 1000NL/min

We are specialized in manufacturing this kind of machine according to the customers' demands.

Furthermore, we have been cooperating with other companies for many years in the world which is based on "reliable quality, multi cavities, long service life, short delivery time and reasonable price".

Welcome to contact with us!
