Canon HV20

Power Supply (rated) Supplied: CA-570 Compact Power Adapter

Supplied BP-2L13 Battery Pack Image Sensor: 1/2.7" CMOS Sensor, RGB Primary Color Filter

Total Pixels Approx. 2,960,000

Effective Pixels: Movies: HDV/DV (WIDE): approx. 2,070,000

DV (NORMAL): approx. 1,550,000

Still Images: 16:9 still images: approx. 2,070,000

4:3 still images: approx. 2,760,000

Maximum Recording Tim:e (with an 80-min. cassette) SP: 80 min.

Lens: Zoom Ratio: 10x Optical/200x Digital

Focal Length: f=6.1-61mm

Zoom Speed: Variable/3 Fixed Zoom Speeds

Max. F/Stop: f/1.8-3.0mm (when tapes are used)

Filter Size: 43mm

nbsp Focusing System: Manual Focus Assist Functions: Magnifying, Peaking&nbsp

Manual Exposure: Yes

Programmed AE: Auto, Program, Av, Tv, CINE, Portrait, Sports, Night, Snow, Beach, Sunset, Spotlight, Fireworks

Supported Playback Modes: 1080/60i, 1080/24P, 1080/30F, 1080/24F

Max Shutter Speed: 1/2000 1/500 (card)

Auto Date/Time:Yes

Record Search/Review:Yes

Minimum Focusing Distance:10 mm (wide)/1m (tele)

White Balance: Daylight, Shade, Cloudy, Tungsten, Fluorescent, Fluorescent H

Image Stabilization: SuperRange Optical (lens shift)

AF System:Instant AF, Through the Lens/Manual Focusing Possible

Viewfinder:Widescreen 0.27" Color Viewfinder/(Approx 123,000 pixels)

LCD Screen:2.7" Widescreen LCD (Approx. 211,000 pixels)

Recording Media:High Definition miniDV (recommended) (63min.) or miniDV cassette

Audio DV:16 bit (2ch) 48 kHz

12 bit (4ch) 32 kHz

4ch synchronous recording not possible

HDV: MPEG1 Audio Layer II (2 ch)

(4-channel playback of tapes containing 4-channel recordings possible)

HDMI Terminal:Type A (19 pins) 480i/ 480p/1080i Format Supported

Microphone Terminal:3.5 mm Stereo Mini-jack

AV Mini Terminal/Headphone Terminal:3.5mm 4 Pole Mini-jack

Dimensions:WxHxD 3.5 x 3.2 x 5.4 in

Weight (not including lens and battery pack) 1.2 lbs

Memory Card:Number of Recording Pixels 4:3 mode: Approx. 2.76 Megapixels (1920 x 1440)

16:9 mode: Approx. 2.07 Megapixels (1920 x 1080)
