Cable cut,cable cutter
Specifications
- Brand
- Yangtze River
- Origin
- China
- MOQ
- 1set
- Packaging
- carton
- Price Term
- EX-Work
- Payment Term
- T/T
- Supply Ability
- 1000set/day
- Delivery Time
- 7days
- Loading Ports
- tianjinxingang
Cable cut,cable cutter is a Electrical Equipment & Supplies product. Key specs — Brand: Yangtze River; Origin: China; MOQ: 1set; Packaging: carton.
Product Description
Cable cut,cable cutter1. Minimized labor in operation with light weight and small size 2. Easy for one hand operation 3. Rachet controlled with relaease option in every cutting position 4. Endurance and antirust by enhanced surface processing and heat-treatment technology 5.
Product supplied with blister card Specification Descriptions / Model No S-24 S-40B remark Wire rope JIS 1 Wire rope(6x7) 18 22 Max Cutting Out Dia(mm) JIS 2 Wire rope(6x12) 24 25 JIS 2 Wire rope(6x19) 24 25 Steel bar Soft steel bar 24 22 Al bar 18 16 Soft bar(SS41 or less) 20 16 Reinforce rod 16 16 Soft wire Cu strands 24(325 ㎟) 41.6(1,000 ㎟) Al strands Cu-al strands(HAL) 24(325 ㎟) 40.7(980 ㎟) High-al strands(ACSR) 24(290 ㎟) 38.4(810 ㎟) Guy wire JIS2 (1x7) 20 15 JIS3 (1x19) 20 20 Cable cut,cable cutter Cable CCP Cable 24 40 Soft cable 24 40 Under ground cable 24 40 Out force(kgf) 4,000 6,000 Max.handle load(kgf) 28 20 Dimensions(L) mm 430 580 Weight 4.0kg 5.7kgCable cut,cable cutter
