CNC foam cutting machine (contour cutting machine )BC1030

Dimensions (L*W*H) 5980*4750*3020MM

Working table size (L*W)3000*2000MM

Handling size (L*W*H) 3000*2000*1200MM

Speed cutter: 0.5-5m/min

Precision: 0.5mm

Weight: 3000kg

Power: 7KW

The machine is most advanced and fully automatic conputerised foam contour cutting machine, can cut the various shape by computerised system.

1.operated by computer and use CAD software to design the shape for the foam block. Make full use of the foam blocks and extremely save the raw material(foam blocks) cost .

2.The operator can monitor the whole process simultaneously and design all the data by themselves .

3.equipped with high precision servo mechanism system;rapid cutting speed and accrurate cutting ;can enhance the working efficiency

4.no dust raise during cutting process ,low noise.

5.operating systm:windows XP/vista

6.designing software :Auto CAD

7.cutting software: foam cutting control system
