CNC Stone Engraving Machine
Specifications
- Brand
- Jingke
- Origin
- China (Mainland)
- Price Term
- FOB
CNC Stone Engraving Machine is a Furniture Making Machines product. Key specs — Brand: Jingke; Origin: China (Mainland); Price Term: FOB.
Product Description
1.square guide rail
2.DSPControl
3.spindle motor:3kw water cooled
4.Artcam software
Machine features:
1).Particular style, competent for elaborate engraving and cutting.
2).2.2KW water-cooled spindle motor.
3).The lathe bed is wholly cast with iron to ensure high stability. Three axes all adopt linear square rail.
4).Be compatible with type 3, Artcut, Artcam software.
5).Memory to ensure the processing point when the blade is broken or postpone situation. Specific saving mode of different points.
Technical parameter:
Modle | JK-6015 |
Work dimensions | 600×1500mm |
Body dimensions | 800×1700×1200mm |
Z-zxis working area | >100mm |
Max.Feeding height | 100mm or bigger |
Cut thickness of material | ≤30mm |
Max.Speed | 6000mm/min |
Working speed | 0-4000mm/min |
Mechanical precision | 0.01mm |
Softwar | type3,Artcut,Artcam software |
Max.Power consumption | 1800W |
Power source | AC 220V/50Hz |
Driver type | stepper motor |
Spindle | 1500W variable speed,water-cooled |
Spindle speed | 0-24,000rpm |
Blade diameter | 1-6mm |
Control system | DSP |
Command | HPGL.G code,u00,mmg,plt |
