CNC Router RC 0404M

This is the newest modle for Metal Molding, we are useing all Cast Steel as the machine body, 25 or 30 HIWIN square rail linear, and HIGH acuuracy ball screws for each asixe. Rapid speed can be 15000mm/min, resolution can be less than 0,01mm.

With lamp, coolant nozzle, special dust hood and water slot to collect the cooling water.

Suitable Materials

Steel molding processing, Brass, aluminum molding processing.....

PARAMETERS NO. Discription Parameter
1 X,Y,Z Working Area 360x400x110mm
2 Table Size 390X550mm

3 Gantry hight 200mm
4 X,Y,Z Traveling Positioning Accuracy <0.01/300mm
5 X,Y,Z repositioning Positioning Accuracy <0.01mm
6 Table Surface T-slot cast steel
7 Frame Cast Steel
8 X, Y, Z Structure Ball Screw and Hiwin sqaure rail linear
9 Max. power Consumption 0.8Kw
10 Max.Rapid Travel Rate 15000mm/min
11 Max.Working Speed 6000mm/min
12 Spindle Power 1.5kw water cooling (Options: 2kw-3.5kw spindles)
13 Spindle Speed 6000-24000RPM (adjustable)
14 Drive Motors Stepper system (Option: Yaskawa, Panasonic servo)
15 Working Voltage AC220V/50/60Hz
16 Command Language G code
17 Operating System DSP System (Mach3 PC Software, NcStiduo)
18 Interface USB
19 Flash Memory 128M(U Disk)
20 Collet ER20
21 X,Y Resolution <0.01mm
22 Software Compatability Type3 software, Wentai software, (Option:Artcam software)
23 Running Environment Temperature: 0℃～45℃
Relative humidity: 30%～75%
24 Packing Size 1580 x 1230 x 1980mm
27 Net Weight 430KG
28 Gross Weight 720KG
All parameters above subject to change without prior notice
