CNC Plasma cutting machine

It can cut any complex plane figures as the large-sized gantry CNC cutting machine and support both flame torch and plasma cutter. It is affordable for all enterprises and workshops. The compact design and rational structure make it lightweight，small size and easy to move. It is usable both indoors and outdoors.

By using high quality controllers in its automation system and antimagnetic materials in its housing, SteelTailor P guarantees a reliable and stable CNC operation.

The application of the most up-to-date CNC technology allows independent programming from numerical control . equipment failure and maintenance difficulty are reduced.

The integration of FastCam cutting software makes drawing, nesting and cutting simple and efficient. The software provides high level of material utilization & optimization

Model	HBST2005LCD-1200*2000
Input Power	220V/110 V 50-60 Hz
Rated Power	180W
Efficient Cutting Range	X Axis : 1200 mm(47”) - Y Axis :2000 mm( 78”) Y Axis: Can be extended till 5500mm(216")
Dimensions of LCD	5.7"
Cutting Thickness( Flame )	0.2”-5.9”(6-150mm )
Weight	70.5kg (156 lbs )
Type of Cutter	Oxy - Fuel or Plasma
Applicable Cutting Fuel	Acetyene , Propane , LPG , Gasoline
Fuel Pressure	Max.0.1MPa (14.5 PSI )
Oxygen Pressure	Max.1.5MPa (218 PSI )
Cutting Software	FastCam
Z Axis Manually Adjustable, Inclinable
