CNC Advertising machine is a Business Services product. Key specs — Brand: Roctech; Origin: China.
Product Description
All meterials for Sign making, even for wood working, molding.
PARAMETERS NO. Discription Parameter
1 X,Y,Z Working Area 600x900x100mm
2 Table Size 720X1140mm
3 X,Y,Z Traveling Positioning Accuracy ±0.03/300mm
4 X,Y,Z repositioning Positioning Accuracy ±0.02mm
5 Table Surface T-slot Extrusions
6 Frame Cast Aluminum
7 X, Z Structure Ball Screw
8 Y Structure Hiwin Rail Linear Bearings and Ball Screw
9 Max. power Consumption 0.8Kw
10 Max.Rapid Travel Rate 6000mm/min
11 Max.Working Speed 4000mm/min
12 Spindle Power Motor 1.5Kw self cooling spindle
13 Spindle Speed 0-24000RPM
14 Drive Motors Stepper system
15 Working Voltage AC220V/50/60Hz
16 Command Language G code
17 Operating System DSP System (Mach3 PC Software)
18 Interface USB
19 Flash Memory 128M(U Disk)
20 Collet ER16
21 X,Y Resolution <0.01mm
22 Software Compatability Type3 software, Wentai software, (Option:Artcam software)
23 Running Environment Temperature: 0℃～45℃
Relative humidity: 30%～75%
24 Packing Size 1710 x 1250 x 1585mm
25 Net Weight 180KG
26 Gross Weight 272KG
All parameters above subject to change without prior notice
