CHAIN SAW GP-5200B

Specifications

Request Quote

Quick answer

CHAIN SAW GP-5200B is a Industrial Power Supplies product. Key specs — Origin: China (Mainland).

Model	GP-5200B
Type	1-cylinder,2-stroke,air-cooled
Cylinder Diameter ×stroke	45×32mm
Displacement	49.6cc
Max.output power	2.2kw/8500 rpm
Fuel oil	Gasoline and two-cycle oil: 25:1
Carburetor	Diaphraqm
Max.ful consumpiton	1.2kg/h
Brake time	0.13s
Start system	self-return hand-operated start
Ignition system	C.D.I
Fuel tank capacity	530ml
Oil tank capacity	310ml
Chain pitch	0.375inch/9.52mm
Chain gauge	0.063inch/1.6mm
Standard length	20"
Weight	6.5~8.5kg
Carton dimensions	510×270×280mm
Bar length	16" 18"
