Listing ID#10013209
ModelGCPR-D23
CategoryTelecommunications
CDMA repeater wide band 20dBm
Specifications
- Origin
- Guangdong,China(Mainland)
- Price Term
- FOB
Quick answer
CDMA repeater wide band 20dBm is a Telecommunications product. Key specs — Origin: Guangdong,China(Mainland); Price Term: FOB.
Product Description
| Specification | Uplink | Downlink | |
| Model Number | GCPR-C20 | ||
| Output Power | 20dBm | ||
| Maximum Gain | ≥60dB | ≥60dB | |
| Frequency | 824-849 Mhz | 869-894 Mhz | |
| Automatic Level Control | ≥20dB | ||
| Intermodulation Products | 9KHz~1GHz | ≤ -36dBm | ≤ -20dBm |
| 1GHz~12.75GHz | ≤ -30dBm | ≤ -20dBm | |
| Spurious Emission | 9KHz~1GHz | ≤ -36dBm | ≤ -36dBm |
| 1GHz~12.75GHz | ≤ -30dBm | ≤ -30dBm | |
| Noise Figure at Max gain, 25ºC (typical) | ≤5dB | ||
| SWR | ≤2.0 | ||
| Group Delay | ≤ 4.5μs | ||
| Power Supply | DC 9V/ 3A | ||
| Mechanical specification | |||
| Dimensions(H*W*D) | 23mm*145mm*175mm | ||
| Weight | 1.5KG | ||
| I/O Connector / Impedance | N-female /(Nominal)50Ω | ||
| Environmental specification | |||
| IP Rating | IP30 | ||
| Operating Temperature | -10~50℃ | ||
| Monitoring specification | |||
| Alarm | specification | ||
| LED indication | Power LED | DC ON/OFF | |
| Alarm LED | ALC1~5dB,orange | ||
| ALC20~25dB,red | |||
