CABLE JACK cable drum jacks Mechanical
Specifications
- Brand
- deli
- Origin
- china
- Certifications
- ISQ9001
- MOQ
- 1piece
- Packaging
- carton
- Price Term
- EXW/EX-Work,FOB
- Payment Term
- T/T,L/C,Western Union
- Supply Ability
- 1000pcs/month
- Delivery Time
- 7days
- Loading Ports
- tianjin
- Guarantee
- ISQ9001
CABLE JACK cable drum jacks Mechanical is a Electrical Equipment & Supplies product. Key specs — Brand: deli; Origin: china; Certifications: ISQ9001; MOQ: 1piece.
Product Description
Product No.: DL013 Product name: Trapezoidal cable drum jack (mechanical type)
Application: applied in the supporting of cable drum when laying cable. Manual-drive and mechanical jacking equipment saves time and labor a lot. With trapezoidal structure, it can be applied in different kinds of reel specification. Trundles installed on the bottom make it easy to move.
You can contact me
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL013-3 3T φ700mm-φ2100mm ≤1500mm φ60mm 96kg
DL013-5 5T φ700mm-φ2400mm ≤1700mm φ76mm 137kg
DL013-10 10T φ700mm-φ3200mm ≤1800mm φ120mm 219kg
Product No.: DL018 Product name: Mechanical cable drum jack
Application: applied in the supporting of reel when laying guiding cable during line construction.
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL018-1 1T φ1160mm-φ1700m ≤1000mm φ60mm 30kg
DL018-3 3T φ1400mm-φ2100mm ≤1400mm φ76mm 40kg
DL018-5 5T φ1600mm-φ2400mm ≤1600mm φ76mm 40kg
Product No.: DL019 Product name: Mechanical cable drum jack
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL019-3 3T φ900mm-φ1800mm ≤1400mm φ76mm 60kg
DL019-5 5T φ1300mm-φ2600mm ≤1600mm φ76mm 85kg
Product No.: DL020 Product name: Mechanical cable drum jack
Application: applied in the supporting of reel when laying guiding cable during line construction.
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL020-1 1T φ700mm-φ1150m ≤1000mm φ60mm 30kg
D020-3 3T φ1300mm-φ2100mm ≤1400mm φ76mm 40kg
DL020-5 5T φ1500mm-φ2300mm ≤1600mm φ76mm 50kg
Product No.: DL022 Product name: Mechanical cable drum jack
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL022-3 3T φ700mm-φ2000mm ≤1400mm φ60mm 50kg
DL022-5 5T φ700mm-φ2400mm ≤1600mm φ76mm 75kg
Product No.: DL023 Product name: Mechanical cable drum jack
Application: applied in the supporting of reel when laying guiding cable during line construction.
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL023-1 1T φ700mm-φ1150m ≤1000mm φ60mm 35kg
D023-3 3T φ1300mm-φ2100mm ≤1400mm φ76mm 43kg
DL023-5 5T φ1500mm-φ2300mm ≤1600mm φ76mm 57kg
Product No.: DL024 Product name: Mechanical cable drum jack
Application: applied in the supporting of reel when laying guiding cable during line construction.
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
DL024-1 1T φ700mm-φ1150m ≤1000mm φ60mm 40kg
D024-3 3T φ1300mm-φ2100mm ≤1400mm φ76mm 50kg
DL024-5 5T φ1500mm-φ2300mm ≤1600mm φ76mm 65kg
Product No.: ISG Product name: Mechanical cable drum jack
Application: applied in the supporting of reel when laying guiding cable during line construction.
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter Dead weight
ISG-2000 2T φ900mm-φ1300m ≤1300mm φ40mm 35.5kg
ISG-3000 3T φ13400mm-φ1840mm ≤1500mm φ50mm 59kg
ISG-5000 5T φ1600mm-φ2000mm ≤1800mm φ70mm 95kg
