Bursting Strength Tester
Specifications
- Brand
- drk
- Origin
- jinan shandong of china
- Price Term
- FOB
Bursting Strength Tester is a Health & Medical product. Key specs — Brand: drk; Origin: jinan shandong of china; Price Term: FOB.
Product Description
Characters:
1. Micro-computer control, use hydraulic oil as the driving force to break the specimen.
2. When the specimen is broken, it automatically stores maximum.
3. LCD displays, the unit of kg, g and MPa in option.
Technical parameters:
DRK 109B |
DRK 109A | |
Power Supply | Power:220V±10 50HZ | |
Circumstance Temperature °C | 20±10 | |
Relative Humidity % | < 80 | |
Value Accuracy | Value Error:±0.5%FS;Value Fluctuation:< 0.5% | |
Hydraulic oil | Silicon Oil 85%, distilled water 15% | |
Horsepower | Shockproof motor 1/4HP | |
Induction way | Pressure converter | |
Indicating way | LCD digital display | |
The Diameter of upper Platen hole mm | 30.5±0.05 | 31.5±0.05 |
The Diameter of Lower Platen hole mm | 33.5±0.05 | 31.5±0.05 |
The dimension of rubber film mm | Thickness 0.8---0.9 | The height of middle bulge 2.5±0.2 The height of middle bulge 27.8 |
The resistance of rubber film mm | When raise 9mm,20-40 | When raise 10mm,170-220 When raise 18mm,250-350 |
The tension between two plasten Kpa | ≥430 | ≥690 |
Sensor Kpa | 2000 | 6000 |
Resolution Kpa | 1 Kpa | 1Kpa |
Oil ml/min | 95±15 | 170±15 |
Dimension | 430×530×520 mm | |
Weight | 65kgs | |
