Biotechnology cabinet

Product Introduction BE-SC-P2-03 IIA2Biohazard safety cabinet is a negative pressure safety equipment which is widely applicable in microbiology, biomedicine, genic recombination, zoopery and biologicals.

It is the basic safety protect equipment in laboratory biologic safety class one protect barrier which adopts advanced air clean technology and negative pressure cabinet design to achieve the protection for environment, person and sample. Airflow:Imbibed air is combined with air in cabinet by the drive of the built-in fan and enter the static pressure box.

30% of air is exhausted through HEPA and 70% of air is sent to operation area for circulation.Applicable Scope:BE-SC-P2-03 IIA2Biohazard safety cabinet is a negative pressure draft cabinet which adopts ULPA and negative pressure cabinet structure. It is applicable in laboratory whose biologic safety class 1 to 3 for experiment of biohazard group 2-3.

It is applicable in biologic experiment which the additive is microcrystalline volatility poisonous chemical substances or capacitated radioactive nuclide.Product Structure:BE-SC-P2-03 IIA2Biohazard safety cabinet is composed by cabinet case, bracket, fan, ULPA and control system.

The case is made of 1.5mm thin cold-roll plate, and the chamber and the reservoir are made of SUS304 stainless steel palte. The double layers structure between the chamber and the ektexine of the cabinet is the air duct. The fan adopts imported fan, and it composes the air cycle system with ULPA and negative pressure air duct.

And a whole system of safety cabinet is composed under the control system composed with microcomputer CMOS chip controlled.Product Feature:Fission type strucure which is composed by cabinet and rack.

Dismountable rack, moveable truckles and balance adjust guide screw are convenient for convery and orientation;Wide LCD screen which can displays various parameters, supplys the user all-wave equipment running state nad safety hidden trouble caution;Intelligent constant wind speed technology with the functions of automatic follow and output adjustment control that can over come the pressure fluctuation caused by fluctuation of power supply and change of filter resistance to ensure biohazard safety; Technical Parameters:Feature of display and control:LCD screen, displays wind speed and pressureSuitable number of people:Two peopleCleanliness:Class100(Fed209E)≥0.5/µm≤3.5/LInflow airflow velocaties:0.56m/sDown airflow velocaties:0.35m/sDown airflowprecision:±0.015 m/sDifferential pressure display range:0-500PaNoise:≤65dbVibration/half peak:≤5µmAverage illuminance:≥650LxAmbinet Temp.:10-30ºC
