BDM10 Moulded Case Circuit Breaker ( MCCB )
Specifications
- Origin
- Zhejiang China
- Price Term
- FOB
BDM10 Moulded Case Circuit Breaker ( MCCB ) is a Circuit Breakers product. Key specs — Origin: Zhejiang China; Price Term: FOB.
Product Description
Detailed Product Description
1,CH model.
2,1,3Pole
3,IEC60947-2.
4,125A,250A
BDM10 MCCB ( MOULDED CASE CIRCUIT BREAKER )
Application
BDM10 series MCCB is applicable circuit of AC 50/60Hz, rated insulation voltage 690V,
rated current 16-250A, for distribute energy of electricity & infrequent making & breaking
circuit in normal conditons, protecting when circuit are overload, short circuit. The product
conforms to IEC60947-2 standard.
Type | BDM10-125 | BDM10-250 | |
Pole | 3 | 3 | |
Rated current ln(A) | 16,20,25,32,40,50,60,80,100,125 | 63,80,100,125,160,200,225,250 | |
Rated insulation voltage Ui(V) | 690V | ||
Utilization category | A | A | |
Rated impulse withstand voltage(KV) | 6 | 8 | |
Rated breaking Capacity (KA) Lcu/lcs | 220/240VAC | 25/7 | 40/40 |
380/415VAC | 18/5 | 25/25 | |
660/690VAC | 12/6 | ||
