B87C Jack hammer
Specifications
- Origin
- Northeast Of Wu Li Ting Crossroads,Fu Ma Road,Fuzh
Quick answer
B87C Jack hammer is a Air Conditioning Systems product. Key specs — Origin: Northeast Of Wu Li Ting Crossroads,Fu Ma Road,Fuzh.
Product Description
The pneumatic breaker mode B87C is tools with compressed air as its compressed air is distributed alternatively through the distributing valve into either end of the cylinder assembly so that the hammer inside is made to carry on a reciprocal motion which impacts the shank of the steel chisel by the tappet drives the chisel into the concrate foundation and makes them split into huge pieces.
| Whole length | 686mm |
|---|---|
| Total weight | 39kg |
| Cylinder diameter | 63.5mm |
| Working pressure | 0.63Mpa |
| Impact energy | 100 10% J |
| Impact power | 1.8 10% KW |
| Impact frequency | 18 5% Hz |
| Air consumption | 55 15% L/S |
| Air pipe inner diameter | 19mm |
| Shank Size | 32mm * 160mm |
