Automatic Three Side Seal Bag Making Machine

Technical Datas

Bagging Mode: 3-side seal pouches

Bagging Speed: Max: 150parts/Min (According To Material & Operating)

Production Lane: 1- 3 lanes

Film Size Range :W=900mm,Max:diameter 640

Pouch Size Range: W=60mm-400mm L=60-300mm (L>300mm,working by multiplied feeding)

Unwinding Unit

Main web shaft: Air shaft

Main web Stand: Half Folded Station

Main web Brake: Magnetic Brake (Mitsubishi Clutch Brake)

L. P. C: Electric Vision Controller (photoelectric sensor)

Main Body

Horizontal Heating Unit: 3 Units (L=460mm W=60mm)

Horizontal Cooling Unit: 2 Units (L=460mm W=80mm)

Vertical Heating Unit: 4 Units (L=720mm W=60mm)

Vertical Cooling Unit: 4 Units (L=486mm W=60mm)

Control System: Computer Control

Table Conveyor:Motor control

Temperature Control:14PCs

Cutter:1set, Seal Bar (Horizontal /Vertical): 11pcs. Tools: 1set

Thermocouple:Attaching Type

Application Material:Sealable laminated film

Main drive: Inverter+Redcucer(optional A.C Motor)

Traction Motor: Equipped with 2 sets of servo motor traction system

The material of the electric heating plates and cooling plates are cold-rolled whole aluminum alloy. 2 string electric heating tubes are in each electric heating plate, power 1.5kw/pc. Upper and lower electric heating plate, power 3kw/plate
