Automatic Door System

Features of Automatic Door:
Type of Automatic Door:DS90 (the light)/DS100 (the weighty)
Model: Single door/Double door of DS90,Single door/Double door of DS100
Door Weight: Max 90kg/2*Max90kg/Max 150kg/2*Max150kg
Door Width: DW700mm-130mm/DW650mm-1050mm/DW700mm-1600mm/DW650mm-1250mm
Power source:AC220V10%,50-60Hz
Open speed:250-550mm/s(Adjustable)
Close speed:250-550mm/s(Adjustable)
Ambling speed:30-100mm/s(Adjustable)
Open time:2-20s(Adjustable)
Lock in force of Automatic Door:>100N
Manual open force:<50N(DS90) <60N(DS100)
Whole consumed power:<150W
Operation environment:-20 degree-+50 degree
Weight Guide way: 11. 3kg (package weight)
Others parts: 11kg (package weight)
Package Guide way: 210*13. 5*14. 5cm
Others parts of Automatic Door: 60. 5*24. 5*15. 5cm
