Automatic Cube Sugar production line

Automatic Cube Sugar production line1.200L copper cookerDescription: This product has the feature of melting sugar,good insulation , simple/easy operation, convenient maintenance, low failure rate and long service life, It is an indispensable equipment in the candy production line Parameters:Capacity(L/pot):200LTotal power:0.75kwExternal dimensions:1000×1000×800mmWeight:150kg2.Storage Tank : heating system is heating the water ,then keep the temperature of the syrup at the demanded temperaure.

This part operate easily and convenientMaterial: stainless steel304;Joint pints: stainless steel.Valve included.Function: Converying the dissolving syrup to the storage tank and keep the temperaturer at 100℃ for preparation of the depositing. Volume 200L

Dimension Ā800*1500 mm

Power 0.37kw

weight 150kg

3.Continuously vacuum cookerThis cooker is comprised of an insulated steel steam pressure vessel, one variable speed product dosing pump, a syrup heating coil, s steam extraction chamber and two receiving vessels,all of which are mounted on a common base special designed continuously vacuum cooker can guarantee the quality of the condensed syrup with stably running,sanitary and humanization designing, and easy to operate and maintainParameters: capacity 300kg/hr

Heating area 2.45㎡

Steam requirement 0.5-0.7Mpa ,about100kg/hr

Temperature of the syrup before cooking 110-115℃

Temperatureof the syrup after cooking 135-145℃

Dimension 1900×1700×2300(mm)

power Dosing pump 0.75kw vacuum pump 5.5kw

weight 800kg

4. Cooling platformDescription: It is used for cooling the sugar after cooking by circulating water.Parameters:External dimensions:2000*1000*700mmWeight::450kg 5.

Double roll flattening machineDescription: This machine can presses evenly cream candy, peanut cream candy, sesame sheet, chewing gum.External dimensions:1350*980*1100mmPower:3kwWeight:800kg6.Cube Sugar Shaping and splitting machineDescription: This machine can shape and split cream candy, peanut cream candy, sesame sheet, chewing gum, such as: rectangular, square etc.

It is featured with continuous production and high output. Parameters:Production capacity:350-400(kg/h)Power(kw):3(380v)External dimensions:11700*1800*800mmWeight:600kg7.6 meters cooling belt conveyorPower:4kwExternal dimensions:6000*700*700mmWeight:380kg
