Aluminum foil container production line CTAC-63T

The production line of food container of aluminium (ordinary model) Modle:CTAC-63T This production line can produce 35 products per minute.(it depends on the production's complexity and size.) Speed can't be regulated.

This prodution line is composed of the followings(note1),1. an auto-lubricated feeder(note2)2. an eletronic controlled panel3. a length controller4. an ordinary 63-T punch5. a set mould of food container6. a automatic conveyor(with carbore which can collect the remainded foil) 7. a collector of finished product Note:production line is electrification integration,and centralized control.width of foil feed system is 520mm.(basic model)feeding system is controlled by computer.

You can regulate the length form 30mm to 999mm.we can manufactured the machine according to the products's size as cutomer required, the outer-appearance of the machine is a little bit different from each other.

The procedure of production line: raw material:aluminium foil-->auto-lubricated feeder-->length controller-->a 63T punch-->mould-->collect product by hand (or auto-collector)-->packing Instrution of Mould: It is said that perfect products should be produced by the good mould which is the goal we endeavor to.

We abandon outdated machanical operation of making mould and adopt the star-up rebounded system which is flexible. The advantages of the mould are long shelf life, stable quality, high precision, and reasonable design. With such advantages, the mould could realize the process of cutting, forming, plugging and rolling of aluminum foil wares at in one step.

We also can manufacture various mould which can be used to make various food container,such as smoothwall container,multi-cavity container,one compartment container and multi-compartment container, and food container with various edges (G style, L style, IVC style or folding style).

The mould is excellent in quality and reasonable in working cycle period is short. According to customers needs, the mould can be seted up to ordinary punch, pneumatic punch,or the press with four pillars.
