Aluminum Die-Casting Radiator

Central Distance:500mm
Weight:1.36kg
Size:80mm*85mm*582mm
Working Pressure:0.9mpa
Water Volume:0.38L
Thermal Output:140W/pc

REMARK OF ALUMINUM DIE-CASTING RADIATOR :

1.Above the data in accordance to EN442 t=50
2.Quality Control Standard Sytem: EN- ISO 9001:2000 and ROHS ,We have CE certification
3.Standard packing: one set/CTN within bubble bag
4.Standard color: RAL9016 Trafic White/RAL9003 Signal White/RAL9010 Pure White
price includes 2 connection nipples and 2 gaskets
6.Warrenty: 5years
use the raw material of ADC12, the international brand which is special to use for airplane.
730 liquid aluminum,die casted by 800T die-casting machine in one step.
material is wearable, and can form the Al2O3 and SiO2 protecting coat, which are anti-grind and anti-corrosion.
10.Twice epoxy resin static electrical spray and roast at 200 make a smooth, durable and bright surface without hazardous substances.
