Advertising plasma cutting machine JCUT-1325

1 .The machine is all welded as seamless steel structure. Steady structure and long life time

2. High configuration, high cutting speed and precision.

3. Auto ARC starting. Steady performance.

4.Control system: DSP handset control, with USB interface

5. Cutting material: steel, copper, iron, aluminum, galvanized sheet, titanium plates, and so on.

6. File format: G-code

7.Suitable Software : Artcut, Type3, ArtCAM. Beihang Haier.

Application:
Processing shells of machinery and electronic products, advertising signs, crafts, iron garden, car manufacture, boat building, electrical accessories, board cutting.

Standard Technical Parameter

Model:JCUT-1325

X,Y working area:1300mm×2500mm

Z working area:150mm

Lathe bed:steel structure with water sink

Machine Power:8.5kw

Working voltage:380V/50HZ

Reposition precision:±0.05mm

Processing precision:±0.1mm

Maximum cutting speed:1500mm/min

Torch Height control mode:Manually

Cutting thickness:0-10mm

Plasma power supply:Hypertherm Plasma power supply made in USA 65A

Control system :DSP

Motors:Stepper

Software:ARTCUT

Weight:700kg

Option:

1.Different working size:

1300X2500MM /1500X3000MM /2000X4000MM or other sizes according to customers’ needs

2.Servo motors and drivers

3.Different power: 65A / 100A / 130A /200A for different thickness cutting

4.Torch Height control system
