Name: AV to VGA convrter
Brand: ADEERI
SKU: ADR-220 AV

AV,CVBS,RCA to VGA converter (Model:ADR-220) can convert the source signals of CVBS,VIDEO and S-VIDEO into VGA adoption of advanced video straight-through technonlogy,the source signals of BNC,AV and S-VIDEO can be converted into VGA signal without any data loss.What’s more,the parameters of the program source such as brightness and contrast are supports plug-and-play,no driver program installation is needed.

Functions

-Supported conversion of video signal format:from CVBS or S-VIDEO signal into frequency multiplication processesd high-resolution VGA signal.
-Multiple input signal formats are supported:CVBS,S-VIDEO,and automatic identifyication of the three color systems i.e.PAL,NTSC and SECAM.
-Supported output resolution: /75Hz, /75Hz,/75Hz, , , , ,
-Adjustable brightness,contrast,color saturation and hue.
-Image freeze
-Current working status can be saved on accidental power-off
-Caption prompts function for all operatrion and status.
-Standard VGA output works with all standard monitor
-Industry-level design(size: 105X65X27mm)
-Power:DC5V/2A supply

Connection Image

Interface Specification

Item

Description

(1)Input

Input selection: AV(CVBS)>>SV(S_VIDEO)>>VGA>>AV(CVBS)
Note:
Reset feature: Press the Input key and power on the set will reset all the setting.

(2)Menu

Menu: Brightness, Contrast, Sharpness, Saturation, Tint, HP(Horizontal position), VP(Vertical position)

(3)Freeze/+
(4)Resolution/-

- If the menu is displayed on the screen, e.g. Brightness, Contrast, Sharpness, Saturation, Tint, HP(Horizontal position), VP(Vertical position):
"Freeze/+" works as "+", such as increase the Brightness, shift the horizontal position.
"Resolution/-" works as "-", such as decrease the Brightness, etc.
- If no menu is displayed on the screen:
"Freeze/+" works as "Freeze"
"Resolution/-" works as "Resolution Selection" for /75Hz,/75Hz,/75Hz,,,,,
Note:Press the Resolution/- will change the output resolution from 800X600 to 1920X1200. If the resolution is too high and your monitor doesn't support it, please keep on press this key to change the resolution to a lower format. Also, you can press the Input key and power on the set will reset all the setting

Item	Spec.
(1)	Connect VGA Display
(2)	Connect AV(CVBS) source
(3)	Connect S-VIDEO source
(4)	Connect VGA source
(5)	Connect DC5V/1A power supply
(6)	Show work staus.

Accessories & Package

Item	Qty	Notes
ADR-220 AV Host machine	1
AV cable	1
S-VIDEO	1
Power	1	DC5V/2A supply
User’s Manual	1	English
