ATV

Model No.:ATV200CC-2 Product Origin:China Brand Name: Price Terms: Payment Terms: Certification: Description:Features: 1) Solid wood composite interior door2) MDF board and infill with wood framework 3) Surface veneered by natural wood skinSpecifications: 1) Dimensions: 1,680mm x 1,030mm x 1,100mm2) Proper mass of empty vehicle: 150kg3) Max. speed: above 45km/h4) Climbing ability: above 20 degrees5) Distance between axles: 1,100mm6) Distance between front wheels: 830mm7) Distance between rear wheels: 780mm8) Ground clearance: 150mm9) Specification of front wheel: 21 x 8-10, 50KPa10) Specification of rear wheel: 22 x 11-8, 50KPa11) Type of engine: 169FML12) Cylinder dia. x working stroke: 69mm x 53mm13) Efficient capacity: 198ml14) Rated power and rotate speed: 10.2kW/8,500r/min15) Max. torque and rotate speed: 13N.m/7,500r/min16) Compressing ratio: 9.2:117) Gear shift mode: five speed / reverse18) Starting system: electrical starting19) Transmission: shaft drive20) Cooling system: air cooling21) Fuel tank: 7.5LPacking:Dimensions: 1,670 x 1,110 x 1,120mmGross weight: 190kg
