Name: 9m 3 Concrete Mixer Truck
Brand: Ming long
SKU: 9m 3 Concrete Mixer Truck

Machine parameters	Name	Unit	Parameters
	Name	Unit	8m 3	8m 3	9m 3
	Model		ZZ5322GJBN3246F	YTQ5290GJB8	ZZ5322GJBN3846F
	Overall length	mm	8264	8040	8550
	Overall width	mm	2480	2490	2520
	Overall height	mm	3800	3800	3800
	Chassis model		Steyr(King size)ZZ1322N3246F	Lsuzu CXZ51K	Steyr(King size)ZZ1322N3846F
	Total vehicle mass	kg	29000	29000	32000
	Mass in working order	kg	11300	11300	12570
	Loading mass	kg	17505	17505	19430
	Wheelbase 1	mm	3225	3225	3800
	Wheelbase 2	mm	1350	1310	1350
	Front wheel distance	mm	1939	2065	1939
	Rear wheel distance	mm	1800	1850	1800
	Tyre type		12.00-20	11.00-20-16PR	12.00-20
	Front suspension	mm	1560	1400	1560
	Rear suspension	mm	1905	2105	1840
	Minimum turn-ing radius	m	7.6	7.0	9.8
	Maximum speed	Kn/h	78	109	73
	Steering gear(Germany)		ZF8098		ZF8098
	Consumption per 100 km( conditions)	L	32		34
Engine	Engine model		WD615.68A;WD615.69	6WF1	WD615.68A;WD615.69
	Engine type		Water-cooling pressure boost inter-cooling direct injection diesel engine	4-stroke water-cooling direct injection	Water-cooling pressure boost inter-cooling direct injection diesel engine
	Number of cylin-ders and arrangement		6-cylinder in-line	6-cylinder in-line	6-cylinder in-line
	Maximum engine power output	kw	228(2200r/min)	287(1800r/min)	247(2000r/min)
	Maximum engine output torque	N·m	1250(1600r/min)	1863(1100r/min)	1250(1600r/min)
	PTO Output	N·m	600(2200r/min)	588(1100r/min)	600(2200r/min)
Working device	Geometric volume of mixing drum	m 3	12.8	12.8	14.7
	Mixing volume	m 3	8	8	9
	Mixing drum inclination angle	degree	15	15	13.5
	Mixing drum rotation speed	r/min	0-14	0-14	0-14
	Water tank volume	L	400	400	400
	Loaded weight	kg	3515	3515	3680
