4.8V battery packs

Jin Hui cell button battery specification

Ni-MH rechargeable battery

Models

(V)

(mAh)

Diameter

Height

Charge Current

Charge Time

Discharge Current

Weight

(mm)

(mm)

(mA)

(h)

(mA)

(g)

B20H

1.2

20

Φ11.6±0.1

3.2±0.2

2

15

4

1.2

B40H

1.2

40

Φ11.6±0.1

5.2±0.2

4

15

8

1.7

B80H

1.2

80

Φ15.1±0.1

6.1±0.2

8

15

16

3.3

B110H

1.2

110

Φ15.1±0.1

7.6±0.2

11

15

22

4.1

B150H

1.2

180

Φ24.4×14.0

5.5±0.2

18

15

36

5.5

B250H

1.2

250

Φ25.0±0.1

6.2±0.2

25

15

50

9.2

B330H

1.2

330

Φ25.0±0.1

8.5±0.2

33

15

66

12

Attention:

We also supply battery packs consist of button cell mentioned above.
