Sophisticated Network Functions: remote surveillance, remote playback, remote recording, remote control DVR ;IE embedded .Various recording mode: timer, motion detection, alarm, and Recording picture quality, resolution & recording frame rate configurableFlexible Display mode : Full Screen, QuadMulti-method searching: Time, Recording event (Alarm, motion detection ), recording listTriplex : monitoring, recording and playback simultaneously.Easy Backup: through network software by scanning HDD and external USB1.1 devicesRemote View: support IE browser and client softwareProtocol: TCP/IP, DHCP, DDNS, PPPoESupport remote menu setupSupport event log listSupport multi lever user management, user rights authourizedSupport PTZ control with preset and auto-cruiseSupport VGA output(optional), direclty connected to LCD. Support USB mouse controlSupport file management, delete or lock every recording file manuallySupport mobile surveillance by smart phonesLow stream, long recording time. Continueously, real time record a month by 250GB| Compression format | H.264 | | Video input | Composite：1.0V p-p/75Ω, BNC×4 | | Video output | Composite：1.0V p-p/75Ω, BNC×2, S-video X 1, VGA X 1(Optional) | | Display Resolution: | 704*576 (PAL), 640*480 (NTSC) | | Record Resolution | 352*288 ,352*576, 704*576 (PAL)320*240 ,320*480, 640*480 (NTSC) | | Display Frame Rate | 100FPS (PAL) , 120FPS (NTSC) | | Record Frame Rate | 100FPS , 50FPS ,25FPS(PAL)120FPS , 60FPS ,30FPS(NTSC) | | Audio input | -8dB --- 22k, RCA X2 (2CH record ) | | Audio output | -8dB --- 92dB, RCA X1 | | Alarm input: | NO or NC, 4CH | | Alarm output: | NO or NC, 1CH | | Record Mode | Manual / Sensor /Timer / Motion detection | | Simplex/Duplex/Triplex | Triplex | | Network Interface | RJ45 (LAN, INTERNET) | | PTZ control | YES | | Communication port | RS485, USB1.1 | | Hard disk info | Support one HDD with no size limitation | | Remote controller | Optional | | Power supply | 12V |
|
|
