45kw generating sets 4BTA3.9-G-50Hz

generating sets 45kw generating sets 4BTA3.9-G-50Hz use:Land Frequency Hz:50Hz YK

Model::kms45p

Product Name:45kw generating sets -50Hz

Model:4BTA3.9-G Prime Power(kw/Kva):45/56 Standby Power(kw/Kva):50/63 Rated Current A:90 Open type Dimension(L*W*H) mm:2280*820*1300 Open type Weight Kg::998 Manufacturer:Cummins

Model:4BTA3.9-G Exhaust:3.9 Continuous/Standby(KW):55/60 Aspiration & Cooling:Turbo/Aftercooled Cylinders Capacity Lt :4 Cylinders & Build :In line Speed RPM :1500 Bore & Stroke mm×mm :102×120 Compression Ratio:17 Fuel consumption g/kw.h :209 Fuel consumption(L/h):16 Lub-oil Capacity Litre :14.2 max oil temperature (℃):121 Coolant Capacity Litre :19.2 Max intake resistance(k Pa):6.2 Max exhaust back pressure:10 Flue gas temperature (℃):502 Thermostat(℃):82-93 Output Voltage V ::400/230 Steady Voltage Adjusting Range:±1% Insulation:H Protection:IP23 Ventilation cooling capacity(1/s):216 Rated capacity(V):24
