3w mr16 12v spotlight is a Spotlights product. Key specs — Origin: CHINA; Price Term: FOB.
Product Description
·Low power consumption.
·Good color rendering.
·Direct replacement for DC12V MR-16 halogen lamp.
·Shock resistance.
3w mr16 12v spotlight Applications
Hotels, restaurants, showrooms, KTV, shopping mall, retail shop
Show case, cabinet
3w mr16 12v spotlight Product Features
Dimension: φ50mm×46mm
Power Consumption:3w
Color Temp: Cool white/Warm white
System Efficiency:100Lm/W
Input Voltage:DC12V
LED Life Span: 50,000Hrs
Safety Cert:CE,ROHS
3w mr16 12v spotlight Product Code
ws-308-0-amr16
3w mr16 12v spotlight Technical Specification
3w mr16 12v spotlight Electrical Characteristiic
Parameter | Symbol | Min. | Typ. | Max. | Unit | Remark |
Power Consumption Input Current Input Voltage Operating Temperature Storage Temperature | P I V Top Tst | - - - -20 -30 | 3 320 3-4 28 25 | - - - 80 60 | W mA Vdc °C °C |
3w mr16 12v spotlight Photometric Characteristic
Parameter | Symbol | Min. | Typ. | Max. | Unit | Remark |
Luminious Flux Color Temperature CRI | Lm CCT - | 270 2500 - | 300 3000 80 | 330 8000 - | Lm K Ra |
