3 Megapixel IP camera

Main Features 1) Up to 2048x1536 Pixels Image resolution 2) Progressive scan CMOS 3) H.264/MPEG-4 video compression with high compression ratio 4) Dual Streams 5) Up to 32 GB SD/SDHC card local storage 6) Auto switch ICR Filter 7) Two-way audio 8) PoE is Optional Specification Camera Image Sensor 1/3" Progressive Scan CMOS Min.

Illumination 0.6Lux F1.2 Electronic Shutter 1/25s~1/100,000s Lens Mount CS Auto Iris DC Drive Adjustment Range Pan0~360°, Tilt0~75°, Rotation0~360° Day Night IR cut filter with auto switch Media Compression Standard Video Compression H.264/ MPEG-4/MJPEG Audio Compression OggVorbis Bit rate 32 Kbps~16Mbps Image Max.

Image Resolution 2048x1536 Frame Rate 50Hz: 12.5fps (2048x1536), 25fps (1920x1080), 25fps (1600x1200); 60Hz: 15fps (2048x1536), 30fps (1920x1080), 30fps (1600x1200) Video Parameter Saturation, Brightness, Contrast adjustable through client software or web browser Network Protocol Protocols TCP/IP, , FTP, DHCP, DNS, DDNS, RTP/RTSP, PPPoE, SMTP, NTP Interface Ethernet Interface 1 RJ45 10M 100M self-adaptive RS485 Interface 1 RS-485 interface Intelligent Alarm Motion Detection, Video Loss, Network Disconnect, IP conflict, Storage exception Alarm Input 2 channel Alarm Output 2 channel Audio Input 1 channel Audio Output 1 channel (Line level, 600Ω) Video Output 1Vp-p Composite Output (75Ω/RCA) Local Storage Support SD/SDHC Basics Reset button, Anti-flicker, Dual Stream, Heartbeat, Password Protection e-PTZ support General Operating Condition -10°~60° Humidity 90% or less Power Supply DC12V±10% Power Consumption 4.5W MAX Impact Protection IEC60068-2-75Eh, 50J;EN50102, up to IK10 Optional PoE (Power over Ethernet)
