3 1/2 Digits Digital Multimeter TM193

Features
- New type holster, streamline design
- Large LCD makes reading easy and clear
- Strong anti-magnetic and anti-jamming performance
- Auto off within 30 minutes
- Full protection function, anti high voltage circuit design
- Unit and function symbols display
- Capacitance test range up to 200uF

Specifications
Basic functions:
DCV: range 2V/20V/200V/1000V, accuracy ± (0.5%+3)
ACV: range 200V/750V, accuracye ± (1.0%+5)
DCA: range 200mA//20A, accuracy ± (0.8%+5)
ACA: range 200mA//20A, acccuracy ± (1.5%+5)
Resistance: range 200Ω/2kΩ/20kΩ/200kΩ/2MΩ, accuracy ± (0.8%+3)
Capacitance: rang 200uF, accuracy ± (3.0%+10)
Rotate speed: range 3CYL/4CYL/5CYL/6CYL/8CYL , accuracy ± (3.0%+5)
Centigrade temperature: range -40℃~1000℃, accuracy ± (0.8%+4)

Special functions:
Diode test :YES
Continuity alarm: Less than 30Ω±10Ω
Low battery indication: Less than 7.5V
Data hold :YES
Auto off: Approx.30 minutes
Function protection:YES
Anti-shock protection:YES
Input impendence: 10MΩ
Sampling rate: 3 times/Sec.
AC frequency response: 40-400Hz
Operation mode: Manual range
Max. display: 1999
LCD size: 57x37mm
Power: 9V (6F22)
Dissipation: Quiescent current: approx.3mA
Size: 155x90x48mm
Net weight: 290g (including battery)
