3G Mobile Security Guards 3G WCDMA surveillance

Product Description

Features

Supports WCDMA 3Gwork visibility monitoring alarm

Built-in 300,000 pixel professional CMOS camera, image clarity

Built-in infrared light, to support real-time wireless video surveillance around the clock

es with PTZ functions, support for up and down angle 90 o, 270 angle around the monitoring

Built-in high-energy lithium-ion battery, smart charger, automatic switching

Built-in microphone, support for monitoring

Built-in speaker, support calls (turn off monitor)

Support Micro SD card (TF card) expansion

Equipped with a wireless remote control arm, disarm and emergency alarm

Built-in WDT, to ensure long-term stable and reliable work

Remote SMS messages (which can set the language), operating private security

work parameter setting function, you can use any open area of WCDMA

SMS, MMS, voice telephony, video phone alarm

Video phone alarm auto-recording, preservation of evidence

Support for screen rotation function to facilitate the safe transfer

Wireless sensor learning, and can support up to 15 (can be more) wireless alarm sensors, system scalability

11 presets (can be more) to receive the alarm telephone number

All wireless systems, installation is simple, easy

At any time, any place can make video phone watch surveillance area

What is inclued in this lising

one (1) piece of WCDMA Visual Alarm Monitoring

one (1) pair of door contact

two (2) pieces of wireless remote controller

one (1) piece of bracket

one (1) piece of power adapter

Technological parameter Type: stand-alone installation

Size: 122 x 100 x 128 mm (with PTZ)

Weight: 200 g

System Information CPU: 32-bit ARM Core

Type A: Dual-Band UMTS / HSDPA 850/1900MHz, GSM / GPRS 850/900/1900MHz

Type B: Dual-Band UMTS / HSDPA 900/2100MHz, GSM / GPRS 850/900/1800MHz

Camera MMS Resolution: VGA (640X480)

Video resolution: QCIF (176X144)

Wireless Sensor Modulation: ASK (315MHz or 433MHz)

Environmental Limits Operating temperature: 0 ~ 70°C

Storage Temperature: -40 ~ 85°C

Ambient Relative Humidity: 5 to 95% (non-condensing)

Power Requirements: Power Input: 5 VDC, ± 5%

Built-in Battery: 900mAh lithium-ion battery, automatic charge

Power consumption: 90 mA at 5 VDC max.

Reliability: Automatic Reboot Trigger: Built-in WDT (watchdog timer)

Warranty: Warranty Period: 1 year
