28W T5 electronic ballast
Listing ID#10013941
CategoryBallasts
Ballasts

28W T5 electronic ballast

Specifications

Origin
China (Mainland)
Request Quote
Quick answer

28W T5 electronic ballast is a Ballasts product. Key specs — Origin: China (Mainland).

Product Description

1x28W,2x28W-T5 Straight Tube ballast
Use Lamp:T51x28W,2x28W
Start-up Mode:non-preheated start
Guarantee Period: 30000 hours
Certificate: CE, CB, CCC, Australia, Nemko, RoHS
Safety Standard:IEC61347-1,IEC61347-2-3,EN61347-1,EN61347-2-3,GB19510.4
EMC Standard:EN61000-3-2,EN61000-3-3,EN61547,EN55015,GB17743,GB17625.1
EEI:EEI=A2
Power Factor:>0.96
Nominal Voltage:AC220-240V
Working Voltage Range: 198-254V
Working Frequency(Hz):> 20kHz
Mains Frequency(Hz):50/60
THD(%):<17
ILCF:<1.7
Width :33MM
Height:21MM
Length:250MM
Max Casing Temperature:70℃
Ambient Temp. Range:-10℃~50℃
