220kw Cummins Generating unit 6LTAA8.9-G2-60Hz

generating sets 220kw generating sets 6LTAA8.9-G2-60Hz use:Land Frequency Hz:60Hz YK

Model::kms220p

Product Name:220kw generating sets -60Hz

Model:6LTAA8.9-G2 Prime Power(kw/Kva):220/275 Standby Power(kw/Kva):232/300 Rated Current A:396 Open type Dimension(L*W*H) mm:2900*970*1600 Open type Weight Kg::2750 Manufacturer:Cummins

Model:6LTAA8.9-G2 Exhaust8.9 Continuous/StandbyKW):220/240 Aspiration & Cooling:Turbo/Aftercooled Cylinders Capacity Lt :6 Cylinders & Build :In line Speed RPM :1500 Bore & Stroke mm×mm :114×144 Compression Ratio:15 Governor :E Fuel consumption g/kw.h :206 Fuel consumptionL/h:62 Lub-oil Capacity Litre 36.7 max oil temperature 121 Coolant Capacity Litre 63 Max intake resistancek Pa)6.2 Max exhaust back pressure10 Thermostat82-93 Manufacturer Leroy Somer Leroy Somer ModelLSA46.2L9 Excitation:Brushless, AVR Output Voltage V :480/277 Steady Voltage Adjusting Range:±1% InsulationH ProtectionIP23 Rated capacityV)24
