Name: 13X APG Molecular Sieve
SKU: 13X APG

13X APG Molecular Sieve Update Time: 2010-5-28 Source: Hits: 20

Type 13X APG molecular sieve is specially designed to co-absorb CO2 and H2O for air cryo-separation industry. It has largeer capacity and faster adsorption speed for removal of CO2 and H2O to prevent the bed gelation, it is suitable for any air cryo-separation plants of any size and any types in the world.

Typical Chemical Formula
Na2Oã€€Al2O3ã€€2.45SIO2ã€€6.OH2O
SiO2 : Al2O3 ≈2.6-3.0

Technical Parameter

Item	Unit	Technical data
Shape		Pellet		Sphere
Diameter	mm	1.5-1.7	3.0-3.3	1.7-2.5	3.0-5.0
Size ratio up to grade	%	≥98	≥98	≥96	≥96
Bulk density	g/ml	≥0.62	≥0.61	≥0.64	≥0.64
Wear ratio	%	≤0.20	≤0.20	≤0.10	≤0.10
Crushing strength	N	≥30/cm	≥70/cm	≥50/piece	≥70/piece
Static water adsorption	%	≥27	≥27	≥27	≥27
CO2 adsorption	%	≥18.5	≥18.5	≥18.5	≥18.5
Water content, as shipped	%	≤1.5	≤1.5	≤1.5	≤1.5

Typical applications
Removal of H2O from air fro air cryo-separation application

Size
13X APG- Zeolites are available in beads of 1-2 mm, (10x18 mesh) 2-3 mm, (8x12 mesh) , 2.5-5 mm, (4x8 mesh) and as powder, and in pellet 1.6”, 3.2”.

Attention
To avoid damp and pre-adsorption of organic before running, or must to be reactivated.
