Listing ID#10039840
Model120-130W
CategorySolar Panels
120-130W Monocrystalline Solar Panel (12V System)
Specifications
- Origin
- China
Quick answer
120-130W Monocrystalline Solar Panel (12V System) is a Solar Panels product. Key specs — Origin: China.
Product Description
| Mono or Poly | Mono |
| Maximum power(Wp) | 120Wp |
| Maximum power voltage(V) | 17.2 |
| Maximum power current(A) | 6.977A |
| Open circuit voltage(A) | 22 |
| Short circuit voltage(V) | 7.793A |
| Number of cells(Pcs) | 36 |
| Size of Module (mm) | 1485*670*35 (156*156mm cell) |
| Temperature Coeff of Volt of Isc(%) | +0.1/ |
| Temperature Coeff of Volt of Voc(%) | -0.38/ |
| Temperature Coeff of Volt of Pm(%) | -0.47/ |
| Temperature Coeff of Volt of Im(%) | +0.1/ |
| Temperature Coeff of Volt of Vm(%) | -0.38/ |
| Temperature Range | -40 +80 |
| Tolerance Wattage(e.g.5%) | 5% |
| Surface Maximum Load Capacity | 60m/s(200kg/sq.m) |
| Allowable Hail Load | steel ball fall down from 1m height |
| Weight per piece(kg) | 12.5kg |
| Juntion Box Type | WITH 3 by pass diodes |
| Connectors and Cables Type | 900mm |
| Cell Efficiency (%) | >14 |
| Module Efficiency (%) | >12 |
| Output tolerance(%) | 5% |
| Frame (Material Corners etc.) | Aluminum |
| Backing (Brand type) | 　 |
| Standard Test Conditions | AM 1.5 100mW/cm2 25℃ |
| Warranty | 2 years product warranty and 20 years 80% of power |
| Certificates | CE, ISO9001-2008 |
