Description Of purling forming machine - 111

purling forming machine - 111 Specificaton & Trade Terms

Model111
Place Of OriginCHINA
Price TermEX-Work
Payment TermT/T
purling forming machine
Introduction
HD Purline Forming Machine can produce many types of C-shaped purline. The

whole line mainly consists of uncoiler and its base, coil sheet flattening

equipment, punching equipment, pre-cutting equipment, C-shape forming

system, hydraulic station, and controlling system.

Product Feature And Usage
The C-shaped purlines formed by this machine have excellent anti-bending

property and are easy to install. They are widely used as the supporter of

roof and wall in large-scale and mid-scale construction, such as factory,

warehouse, garage, exhibition center, cinema, theatre, garden and so on.

Suitable Material For Production
Cold-rolled steel strip and heat-treated galvanized steel strip
Size of material: (192-422)mm*(2.0-3.0)mm*Lmm.

Main Technical Specification
1.Size: 23000mm*mm*mm
2.Total weight: about 13,000kg
3.Controlling system: PLC
4.Main motor power: 15kw Levelling motor power: 2.2kw
5.Working speed: 8000-10000mm/min
6.Hydraulic pressure: 18-20Mpa
7.Product range: all the type from 100 to 240
