home theater projector

Model: HPT035-HD
Origin: China
Details: Model: HPT035-HD
This model Support HD 1080i/720P/576p/576i/480p/480i Signal Input,is Home theater HD projector TV;
With HDMI/SCART input. And TV Tuner Built-in; Includes VGA(D-Sub15pinx1)/AV(VCD/DVD)/S-Video... input.Support HD And Picture-in-picture Display...
Equipped with inputs such as AV,SV,YPbPr/YCbCr,SCART,HDMI,DTV,DVB-T,TV,USB,3.1 card reader, etc...(the above inputs may vary for different projector models) ;
-
Main Function:
1. DDHD/ HDTV(with HDMI/Scart/TV/DVB-T(Choice) support HD 1080i/720P/576p/576i/480p/480i) Multimedia Projector;
2. Portable projector Small size, high brightness with compact design and light weight. Excellent display with high brightness and contrast ratio;
3. Highly compatible with various computer and video input signals within a horizontal frequency range of 15 to 110kHz and a vertical frequency range of 45- 85kHz (VGA-XGA)
4. Manual zoom control enables user to adjust the screen between 1.1m (35inch) ~10.0m (230inch); Power protection/automatic shutdown, automatic reversal screen, Digital keystone correction(+/-15 degrees);
-
Other features:
1. Support all system TV signals;
2. Advanced image enhance technologies: ACM(Adaptive Color Management)&ACC(Adaptive Contrast&Color)&DCDI(Directional Correlational De-Interlace);
3. OSD screen display function;
4. Support vertical or horizontal image flip & zoom and a free switch of 4:3 and 16:9;
5. Support dynamic, soft, standard and personal 4 picture mode settings;
6. Support standard, news, music and personal 4 sound modes ;
7. Support off, weak, middle and strong 4 noise reduction modes;
8. Optical keystone correction;
9. Fans continue working after shutdown of HPT (lasting for 7 minutes to prolong the lamp life);
10. Easy operation with an IR remote control ;
11. Manual focus adjustment ;
12. Adopt reasonable, low noise ventilation system;
13. Equipped with high brightness, highly effective optical engine system ;
14. Easy replacement of bulb ;
15. Safety designs: power off confirmation, high temperature automatic shutdown, fan error alarm & shutdown;
16. Support automatic power off when no signal input (not for TV);
-
i). Optical parts:
1. Display Tech: LCD (liquid crystal display)
2. Physical Resolution: 3.5 inch SVGA (800 x600) Lcd panels
3. Support Resolution: VGA, SVGA, XGA (640*480 to 1024*768)
4. Contrast (Black/White): 600:1
5. Brightness (53inch): about 2000 ANSI Lumens
6. Projection Lens: Manual zoom/focus adjustment
7. Lamp & Life: 150W Metal Halide lamp /6000 Hours
8. Width/high ratio: 4:3/16:9
9. Digital keystone correction: Vertical: +/- 15 degrees
10. Projection Distance &screen size: 1.1m (35inch)-10.0m (230inch)
12. Noisy (db): <32dB
13. Uniformity: 95%
14. Color: 16,770,000
15. Video Compatibility:NTSC4.43;PAL-60,PAL-M,N,(B,D,G,H,I);SECAM;720P,576p,576i,480p,480i
16. Scanning frequency: Horizontal: 15-110kHz; Vertical: 45-85 Hz
17. Audio System: 1x 2w
18. Computer Input: D-Sub 15 pin
19. Input & Output: Scart, HDMI (with HDCP),TV,AV IN/Y/PB/PR, Audio,RS232,VGA( D-Sub 15pinx1),S-Video, RGB-IN, USB(Choice),DVB-T(Choice)
ii). other:
1. Menu Language: 8 Languages
2. Fans: Thermal delay functions (7-minute delay, extend lamp life)
3. Power/Voltage: AC 90V~140V &210V~240V,50-60 Hz
4. Power Consumption: <220 W
5. Weight: N.W:3.5Kg; G.W:5.5Kg
6. Dimensions (WxDxH): 298X224X98 mm
7. Regulatory: CE
-
Note:
1. Brightness is no uniform measurement method, the manufacturer's specifications vary. The brightness value of the factory when the factory typical and brightness set to 100% as a standard.
2. The actual lamp life may be under different environment and different. May affect lamp life of factors including temperature, elevation, Quick Switch machine and the standard model and the low-power mode between conversions;
-
Accessories:
Standard Accessories:
User's Manualx1;
Video Cable(RCA Type)x1;
Power Cord x 1;
S-Video Cable x 1;
D-Sub 15pin Cable(VGA) x 1
Remote Controller x 1;
Lens Cap x 1
-
Optional Accessories:
1. Spare lamp, 2. Projector Ceiling Mount
3. 84 inch Manual glass bead projection screen; 4. 84 inch Electric glass bead projection screen
5. 100inch Manual glass beads projection screen; 6. 100 inch Electric glass bead projection screen
