automatic tea packing machine (KVDC-10B) - KVDC-10B

KVDC-1OB Tea Bag Packing Machine is a kind of machine used for packing tea seeds, medical, health-care and tea industries granular shaped ingredients. All of these items could be packed with both inner and outer envelops, and with thread and tag at the same time.

The processes of bag making measuring, filling, sealing, cutting, counting and hot pressing code can be done automatically. Handling thread and tag would be a specific point of this machine, which would be a good convenient for customers while drinking tea.

Bag size of inner bag: long 50-60 mm, wide 30-80 mm

Bag size of outter bag:long 60-120mm,wide 70-90mm

Production capacity:20-40 bag per min

Filling range:2-12ml per bag

Power:220V,50HZ,3.35KW

Weight:700kg

Dimension(LxWxH) 1200x850x1900 mm
