automatic powder packing machine - KVDF-40II

Applications:

The machine is designed and manufactured specially for powdery and super fine powdery products Driven by servomotor, the auger is rotating to fill products; furthermore, the filling range can be adjusted automatically through computer.

The processes of bag making, measuring, filling,sealing, cutting, counting and hot pressing codes can be done automatically.

Packing material include several kinds of heat-seal lamination, such as PET/plated AL/PE, PET/PE, NYLON etc.

Features:

1. All stainless steel cover meets to GMP standard.

2. Equipped with antipollution and dustproof device.

3. Automatic adjustment of pouch size and filling range.

4. Automatic self support lubricating system, the machine can work 24 hours.

5. The operation facility is controlled by American intel computer, all function is displayed with digital screen.

6. Minimum sealing temperature variation employs PID temperature, the tolerance is controlled by plus-minus 2%.

7. Equipped long filling screw make the sealing area clean and strong and compact shut-off door is used to prevent from product clamping at sealing jaw.

8. Ink printer and conveyor are as an option.

Model KVDF-40II
Bag size Long 55-110 mm; Wide 30-80 mm
Capacity 40-80 bags/min
Max filling range 40 ml
Power 220V, 50HZ,1.5KW
Weight 330 kg
Dimension 600x790x1780mm





Model KVDF-150II
Bag size Long 70-150 mm; Wide 70-115 mm
Capacity 35-60 bags/min
Max filling range 150 ml
Power 220V, 50HZ,1.9KW
Weight 350 kg
Dimension 700x800x1900mm
