automatic granular packing machine - KVDK-40II

Applications:

The machine is suitable for packing non sticky, bulk or granular material, such as medical pills, food Stuffs, plant seeds, washing powder, coffee, sugar, desiccant etc.

The integrated processes of bag making, measuring filling, sealing cutting, counting and hot pressing codes can be done automatically.

Packing material include several kinds of heat seal lamination, such as PET/plated AL/PE, PET/PE, NYLON etc.

Features:

1. All stainless steel cover meets to GMP standard.

2. Equipped with antipollution and dustproof device.

3. Automatic adjustment of pouch size and filling range.

4. Photocell controller is easy to manipulate.

5. Automatic self support lubricating system, the machine can work 24 hours .

6. The operation facility is controlled by American intel computer, all function is displayed with digital screen.

7. Minimum sealing temperature variation employs PID temperature, the tolerance is controlled by plus-minus 2%.

8. Along with assembling automatic no packing alarm system, help user to economize cost.

9. Equipped with easy open system.

10. Ink printer and conveyor are as an option.

Model KVDK-40II
Bag size Long 55-110 mm; Wide 30-80 mm
Capacity 50-110 bags/min
Max filling range 40 ml
Power 220V, 50HZ,1.5KW
Weight 320 kg
Dimension 600x790x1780mm





Model KVDK-150II
Bag size Long 70-150 mm; Wide 70-115 mm
Capacity 35-60 bags/min
Max filling range 150 ml
Power 220V, 50HZ,1.5KW
Weight 340 kg
Dimension 700x800x1900 mm
