Swivel link &Swivel Joint - 001

Swivel link &Swivel Joint - 001
:
bazhou deli power tools factory
: 2013-06-20 23:27:50
:
Connector Swivels

Inquiry Supplier / Manufacturer
Description Of Swivel link &Swivel Joint - 001

Swivel link &Swivel Joint - 001 Specificaton & Trade Terms

Model001
Place Of OriginChina
Packagingcarton
BrandDeLi
Price TermFOB
Payment TermT/T
Supply Ability1000
Minimum Order1
Loading Portstianjinxingang
Delivery Time7days
Swivel link &Swivel Joint
Line swivel/swivel link is made by high strength stainless steel material, light weight,can pass through the cable block.It is the best for connecting and pulling steel wire rope.
Order
Number Model Main Size(mm) Rated Load
(kn) Weight
(kg)
A B C D E
17122 SLX-1 35 100 70 12 13 10 0.4
17124 SLX-3 37 129 95 16 16 30 0.65
17125 SLX-5 42 154 116 18 17 50 1.5
17126 SLX-8 57 220 165 24 22 80 2.4
17127 SL130 62 248 192 26 24 130 3.5
17128 SL180 75 294 222 26 26 180 7.2
17129 SL250 85 331 251 30 30 250 10.6
Swivel link &Swivel Joint
