Pyramid anchor - 5888749

pyramidal anchor
Size: 25#-1000#
Pyramid shaped,one piece
Cast iron, permanent mooring anchor
Fresh or salt water use
Works well in a hard rocky or sandy bottom. Work well in tidal waters as the attached chain does not tend to wrap around the anchor shaft which is possible in an improperly set mushroom anchor.
The Pyramid shaped, one piece, cast iron, permanent mooring anchor is for fresh and salt water use. Pyramid Anchors work well in a hard, rocky or sandy bottom. This anchor works well in tidal waters, because the attached chain does not tend to wrap around the short anchor shaft. Mooring will rapidly set itself by presenting a digging edge to penetrate the bottom. The short shank allows mooring in more shallow water with less chain wrap-up and potential hull damage. The large diameter eye is designed to accommodate a proper size shackle and chain for recommended mooring weights.
Boat Length Pyramid Anchor Weight
Up to 10 ft 25 lbs
14-16 75 lbs
16-18 100 lbs
18-20 150 lbs
20-24 200 lbs
25-29 250 lbs
30-32 300 lbs
