Iron Melting Induction Furnace 50KG - GW50KG Specificaton & Trade Terms
| Model | GW50KG |
|---|
| Place Of Origin | China |
|---|
| Packaging | Plywood cases and nude |
|---|
| Brand | Jinhuaxin |
|---|
| Price Term | EX-Work |
|---|
| Payment Term | T/T |
|---|
| Supply Ability | 40set/month |
|---|
| Minimum Order | 1 set |
|---|
| Loading Ports | qingdao |
|---|
| Delivery Time | 15-30 days |
|---|
1.Production Name: Iron Melting Induction Furnace 50KG
2.Production Description:
Furnace Model GW-0.05T-100KW/2.5S
Rated Capacity T 0.05
Max. Capacity T 0.06
Rated Power KW 100
MF Frequency KHZ 2.5
Power Input Voltage V 380
MF Output Voltage V 750
Pulse 6
Melting Rate T/H 0.17
Melting Time Minutes/batch 18
Electricity Consumption KWH/T 620
Transformer Capacity KVA 120
Water Cooling Consumption T/H 5
3.Usage: Iron Melting Induction Furnace Mainly used in melting iron, cast iron, grey iron, is with high melting efficiency, good electricity saving effect, good metal component uniformity, less burning loss, speedy temperature rise, easy control of temperature, is suitable to all kinds of metal melting.
4.Characters and Advantages:
1) Constant power output, speedy melting, good electricity saving efficiency.
2) Zero-voltage sweep-frequency style start, adapts to requirement of frequently start.
3) Comprehensive protection functions, such as overcurrency protection, overvoltage protection, current-limiting protection, voltage-limiting, water-break protection, and default protection, equipment runs reliably under premise of melting speed guarantee.
4) Easy to operate, suitable for all casting process.
5) Aluminum Shell, lower in purchase cost.
5. Package: Plywood cases and nude
6. Min. Order: 1 set
7. Delivery Time:15-30 days
8. Payment Term: 30% DEPOSIT, BALANCE REST BY T/T IN ADVANCE.
9. Offer Technical guide/installation/adjustment
