Excavator - SWE150LC-1-1-1-1-1-1 Specificaton & Trade Terms
| Model | SWE150LC-1-1-1-1-1-1 |
|---|
| Place Of Origin | China |
|---|
| Price Term | EX-Work |
|---|
| Payment Term | T/T |
|---|
Key Specifications/Special Features:
• Operating weight: 14,500kg
• Standard bucket capacity: 0.56m³
• Bucket digging force: 90kN
• Traveling speed: 5.0/3.2km/hour
• Maximum gradeability: 35°
• Swing Speed: 11.1rpm
• Engine model: ISUZU AA-4BG1TCG-04
• Engine type: 4-stroke water-cooled
• Engine displacement: 4.329L
• Engine maximum power/rpm: 89kW/2200rpm
• Engine fuel tank: 245L
• Hydraulic type: Kawasaki KPM
• Main pump of hydraulic: 2 piston pumps
• Main valve brand: Kawasaki KPM
• Specification of main valve: KVMM-160-XA C0170-41016
• Swing motor type: Nabtesco
• Specification of swing motor: GM21VA-A-50/79-1 i = 50
• Travel motor type: Kawasaki KPM
• Specification of travel mote: M2X63CHB-RG06D
