Cable Reel Puller/ Cable Reels/ Cable reel carrier

Inquiry Supplier / Manufacturer
Description Of Cable Reel Puller/ Cable Reels - dl-8

Cable Reel Puller/ Cable Reels - dl-8 Specificaton & Trade Terms

Modeldl-8
Place Of Originchina
Price TermEX-Work
Payment TermT/T
Cable Reel Puller/ Cable Reels/ Cable reel carrier trailer
Cable drum trailer

1,Mechanical
Application: used for cable drum hauling and cable pulling-pushing.

Adopt mechanical lifting method, simple operation, stable and durable. The traction tire on the font of cable trailer can change angle at random and easy to move. Equipped with damping device, the stability of trailer was increased greatly.

Remarks: the trailer can be transported by container after disassembly.

Please contact us is you have any requirement, and we can make products with special specification as your requirements.

Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter
HT1011-3 3T ≤φ2400mm ≤1400mm φ76mm
HT1011-5 5T ≤φ2800mm ≤1600mm φ90mm
HT1011-8 8T ≤φ3400mm ≤1800mm φ120mm
HT1011-10 10T ≤φ3600mm ≤2000mm φ150mm

2,Hydraulic
Application: used for cable drum hauling and cable pulling-pushing. Equipped with hydraulic hand device, can lift cable drum easily. The traction tire on the font of cable trailer can change angle at random and easy to move. Equipped with damping device, the stability of trailer was increased greatly. Remarks: the trailer can be transported by container after disassembly.
Please contact us is you have any requirement, and we can make products with special specification as your requirements.
Product No. Rated load Applicable drum diameter Applicable drum width Axle bar diameter
HT1012-3 3T ≤φ2400mm ≤1400mm φ76mm
HT1012-5 5T ≤φ2800mm ≤1600mm φ90mm
HT1012-8 8T ≤φ3400mm ≤1800mm φ120mm
HT1012-10 10T ≤φ3600mm ≤2000mm φ150mm
